Product Details
| Properties | Data |
| Delivered pressure | 8.5 bar |
| Distance between bolts | 80×80 mm |
| Electrical connection | Bayonet DIN 72585 |
| Max. operating pressure | 8.5 bar |
| Mounting | 3x M8 |
| Port thread 11 | M22 x 1.5 JED – 388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-0 |
| Port thread 22 | M22 x 1.5 JED – 388-0 |
| Port thread 3 | Integrated Silencer |
| Port thread 42 | M16 x 1.5 JED-388-0 |
| Port thread 43 | M16 x 1.5 JED-388-0 |
| Voltage | 24 V |
Comparison Numbers
| Replaces | Referans No | Alternative No |
| DAEWOO | 345440 3480 | 3454403480 |
| DAEWOO | P34544 03480 | P3454403480 |
| DAF | 1601034 | |
| DAF | 0004319413 | |
| DAF | 1315695 | |
| DAF | 4103223 | |
| DAF | 41211417 | |
| DAF | 81523016208 | |
| EVOBUS | A0004319413 | |
| HINO | S4780E0070 | |
| HYUNDAI | 59710 7K000 | 597107K000 |
| IRISBUS | 41211417 | |
| ISUZU | 1482401911 | |
| IVECO | 41211417 | |
| IVECO | 41032232 | |
| IVECO | 0004319413 | |
| IVECO | 1315695 | |
| IVECO | 1601034 | |
| IVECO | 4103223 | |
| IVECO | 81523016208 | |
| LEYLAND DAF-PACCAR | 1601034 | |
| MAN | 81.52301.6208 | 81523016208 |
| Mercedes-Benz | 000 431 8713 | 0004318713 |
| Mercedes-Benz | 000 431 8913 | 0004318913 |
| Mercedes-Benz | 000 431 9413 | 0004319413 |
| Mercedes-Benz | A000 431 8713 | A0004318713 |
| Mercedes-Benz | A000 431 8913 | A0004318913 |
| Mercedes-Benz | A000 431 9413 | A0004319413 |
| Renault | 50 21 208 480 | 5021208480 |
| Scania | 1935136 | |
| SCHMITZ CARGOBULL | 1042024 | |
| SCHWARZMÜLLER | 97456 | |
| SHAANXI | DZ95259364002 | |
| SOLARIS | 1102219001 | |
| UD TRUCKS | 4528900Z05 | |
| VAN HOOL | 11167595 | |
| VDL | 297659 | |
| VDL | 20297659 | |
| Replaces Wabco | 480 204 002 0 | 4802040020 |
Application
| Vehicle Brand | Model, engine, gearbox, axle, cab |
| Iveco Stralis | Stralis (tbd) 2002 – 2019 |
| Iveco S-Way | S-Way 2019- 2019 – 0 |
| Iveco Trakker | Trakker (tbd) 2004 – 2021 |
| Iveco X-Way | X-Way 2019- 2019 – 0 |
| MAN Lion’s | Lion’s City |
| MAN N-Busse | NL |
| MAN TG-Serie | TGL 2004 – 0, TGM 2004 – 0 |
| Mercedes-Benz Actros 1 | 950, 952, 953, 954, tbd |
| Mercedes-Benz Actros 2 | 930, 932, 933, 934, 938, tbd |
| Mercedes-Benz Actros 3 | 930, 932, 933, 934, 938, tbd |
| Mercedes-Benz Atego 1 | 950, 952, 953, 954, 970, 972, 974, 976, tbd |
| Mercedes-Benz Atego 2 | 970, 972, 974, 976 |
| Mercedes-Benz Axor | 375, 940, 942, 943, 944, 950, 952, 953, 954, tbd |
| Mercedes-Benz Econic 1 | 957, tbd |
| Neoplan Neoplan | Skyliner |
