Product Details
| Properties | Data |
| Max. operating pressure | 10.0 bar |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 3x Ø 11.0 mm |
| Port thread 1-4 | M14 x 1.5 ( E ) |
| Port thread 11 | M16 x 1.5 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 72 mm |
Comparison Numbers
| Replaces | Referans No | Alternative No |
| DAF | 1505139 | |
| DAF | 1505139A | |
| DAF | 1505139R | |
| DAF | 1518247 | |
| Mercedes-Benz | 001 295 2107 | 0012952107 |
| Mercedes-Benz | 001 295 2207 | 0012952207 |
| Mercedes-Benz | 001 295 3107 | 0012953107 |
| Mercedes-Benz | 001 295 3907 | 0012953907 |
| Mercedes-Benz | 001 295 6707 | 0012956707 |
| Mercedes-Benz | 001 295 6707 80 | 001295670780 |
| Mercedes-Benz | A001 295 2107 | A0012952107 |
| Mercedes-Benz | A001 295 2207 | A0012952207 |
| Mercedes-Benz | A001 295 3107 | A0012953107 |
| Mercedes-Benz | A001 295 3907 | A0012953907 |
| Mercedes-Benz | A001 295 6707 | A0012956707 |
| Mercedes-Benz | A001 295 6707 80 | A001295670780 |
| Renault | 50 21 170 433 | 5021170433 |
| Scania | 1935590 | |
| Setra | 8.383.231.000 | 8383231000 |
| Setra | 8.383.240.000 | 8383240000 |
| Van Hool | 637208670 | |
| Replaces Wabco | 970 051 131 0 | 9700511310 |
Application
| Vehicle Brand | Model, engine, gearbox, axle, cab |
| Mercedes-Benz MK-Series (OM 400) | 621, 645 |
| Mercedes-Benz NG-Series (OM 400) | 620 |
| Mercedes-Benz SK-Series (OM 400) | 621, 622, 623, 624, 645, 646, 647, 648, 649 |
